Group of low, pale faceted rocks with a larger central stone.

Shapes & Seasons Farm · Nature

Rock cluster, three-quarter view on a neutral backdrop

Drag to orbit after opening. The model starts stationary.

Revision r_37cde8b1f8d344aa8f6142aeab61a62e

Metres · +X forward · +Y up · +Z right

The poster is this revision’s sealed GLB rendered under the Kiln review lighting rig (review-neutral-v1) on the neutral backdrop, with nothing retouched. The 3D view applies the same rig (review-neutral-v1): its light directions and strengths, exposure, tone mapping and backdrop.

For your engine. The download is a standard glTF 2.0 binary (GLB) with PBR metallic-roughness materials. glTF stores materials, not lighting or tone mapping, so your engine decides how they read. This 3D view tone-maps with Review Neutral, the Khronos PBR Neutral construction with a smaller glare offset (0.015 instead of 0.04), at exposure 0.9. Its Tone mapping control also shows ACES and Linear, for comparison.

Triangles
400
Meshes drawn
1
Materials
1
Bounds · X × Y × Z
1.07 × 0.65 × 1.50 m
Animation clips
None

Review views

Six views of this revision, rendered on the GPU from its source.

Six rendered review views of rock-cluster.
Material-faithful GPU source review views for r_37cde8b1f8d344aa8f6142aeab61a62e.

Read the actual source.

Download .kiln.js

This is the source extracted from the sealed editable archive for the displayed revision.

rock-cluster.kiln.js
const meta={name:'Rock cluster',role:'prop'};

function merge(gs) {
 const p=[], n=[], uv=[];
 for (const source of gs) {
  const g=source.index?source.toNonIndexed():source;
  g.computeVertexNormals();
  const pa=g.getAttribute('position'),na=g.getAttribute('normal'),ua=g.getAttribute('uv');
  for(let i=0;i<pa.count;i++){p.push(pa.getX(i),pa.getY(i),pa.getZ(i));n.push(na.getX(i),na.getY(i),na.getZ(i));uv.push(ua?ua.getX(i):0,ua?ua.getY(i):0);}
 }
 const out=new THREE.BufferGeometry();
 out.setAttribute('position',new THREE.Float32BufferAttribute(p,3));
 out.setAttribute('normal',new THREE.Float32BufferAttribute(n,3));
 out.setAttribute('uv',new THREE.Float32BufferAttribute(uv,2));
 return out;
}
function boulder(c,s,seed,floor) {
 const g=new THREE.IcosahedronGeometry(1,1),p=g.getAttribute('position');
 for(let i=0;i<p.count;i++){
  const x=p.getX(i),y=p.getY(i),z=p.getZ(i);
  const r=1+0.07*Math.sin(x*4+seed)*Math.cos(z*5-seed)+0.035*Math.sin(y*7+seed);
  p.setXYZ(i,c[0]+s[0]*(x*r+0.09*y),Math.max(floor,c[1]+s[1]*y*r),c[2]+s[2]*(z*r+0.06*x));
 }
 g.computeVertexNormals(); return g;
}

function build(){
 const root=createRoot('RockCluster');
 // Five original deterministic closed stones; 4 cm intentional ground embedding.
 const stones=[
 {name:'Keystone',c:[-.1,.26,-.08],s:[.43,.34,.40],seed:14},
 {name:'EastShoulder',c:[.06,.18,.40],s:[.31,.26,.33],seed:22},
 {name:'EastToe',c:[-.34,.12,.48],s:[.24,.18,.27],seed:31},
 {name:'WestShoulder',c:[.19,.14,-.43],s:[.30,.21,.32],seed:41},
 {name:'WestToe',c:[-.33,.10,-.46],s:[.25,.16,.29],seed:53}
 ];
 const stone=gameMaterial(0xa39d8c,{roughness:.96,metalness:0});
 const g=merge(stones.map(v=>boulder(v.c,v.s,v.seed,-.04)));
 const part=createPart('Five_adjoining_stones',g,stone,{parent:root});
 part.userData.stones=stones.map((v,i)=>({name:v.name,firstTriangle:i*80,triangleCount:80,center:v.c}));
 return root;
}

Source SHA-256: 2ee4fed4c668f28260911affd4a9ee9c58cf1b416fcbd4a3fe1d657e97191868

Named part paths (1)
  • RockCluster/Mesh_Five_adjoining_stones

Follow the saved revisions.

Originally authored by GPT-6 Astra. No separate refinement model is recorded for this delivery.

  1. first

    GPT-6 Astra · Codex 0.157.1

    Requested effort: high. Independently confirmed: high.

    r_37cde8b1f8d344aa8f6142aeab61a62e
