Kinetic wave
Articulated teal and bronze fins on a dark plinth
Earlier examples from earlier Kiln versions.

Drag to orbit after opening. The model starts stationary.
For your engine. The download is a standard glTF 2.0 binary (GLB) with PBR metallic-roughness materials. glTF stores materials, not lighting or tone mapping, so your engine decides how they read. This 3D view tone-maps with Review Neutral, the Khronos PBR Neutral construction with a smaller glare offset (0.015 instead of 0.04), at exposure 0.9. Its Tone mapping control also shows ACES and Linear, for comparison.
Build measurements
- Triangles
- 18,960
- Estimated draws
- 273
- Materials
- 7
- Textures
- 0
- Animation clips
- 1
- Bounds X × Y × Z
- 0.64 × 1.6 × 1.8 m
- Build warnings
- 0
Measurements come from this build.
Download this build
Runtime: 207,452 bytes. Original: 207,224 bytes.
These GLBs are build outputs of the MIT-licensed example source; no separate terms are stated for the builds.
Runtime provenance metadataSHA-256 download hashes
- Runtime GLB
- be520de4f30395b448d8cca1b750c157d126da872007dd2b241bbcf80a2a591d
- Original GLB
- 4d7974c5c7ea1f6cec4ce934dcb37efb084838f760ccc08711fa1a22444b6cab
- Source
- fd9973630d17faf48d8486f2a62edf951f9873357436cf14e8c3a8c99424f66f
The example source is part of the Kiln repository. Repository licence: MIT.
These GLBs are build outputs of the MIT-licensed example source; no separate terms are stated for the builds.
Recorded authorship
Gemini 3.8 Flash through Antigravity CLI (agy) ·
Recorded Antigravity / gemini-3.8-flash-high run; configured model, no provider-internal attestation.
- Source access
- Fresh project-local authoring workspace with a brief, installed skills and Kiln tools.
- Inherited context
- Fresh independent authoring conversation.
- Starting example
- None supplied.
- Human input
- Maintainer supplied the brief and reviewed actual exports and uniform gallery posters. Final source bytes are preserved from the model export.
- Authoring review
- Actual GPU images inspected independently. A stylized kinetic sculpture; mechanical clearance has not been certified.
Picture rendered from an earlier revision of this source.
The source behind this build
// Maintainer revision: flush-face fix (2026-11-12, Claude Sonnet 5.5 via Claude Code): 1 part edit that separates coplanar faces; materials, names, hierarchy and animation are unchanged.
const meta = {
name: 'Museum Kinetic Wave Sculpture',
category: 'prop',
role: 'prop',
};
// Generates an aerodynamic sculpted wave fin mesh with smooth mathematical curvature
function createFinBladeGeo(u, height, sweepX, archZ, twistDeg, chordBase, thicknessBase) {
const K = 20; // Height stations
const M = 16; // Perimeter samples
const positions = [];
const uvs = [];
const indices = [];
// Bottom center vertex for watertight root closure
const bottomCenterIdx = 0;
positions.push(0, 0.04, 0);
uvs.push(0.5, 0.0);
// Slices 0 to K-2
for (let k = 0; k < K - 1; k++) {
const t = k / (K - 1);
const y = 0.045 + height * t;
const curl = 0.035 * Math.sin(Math.PI * u) * Math.pow(Math.max(0, t - 0.65) / 0.35, 2.0);
const sx = sweepX * Math.pow(t, 1.75) - curl;
const sz = archZ * Math.sin(Math.PI * t);
const currentTwist = (twistDeg * Math.PI / 180) * t;
// Sculpted chord envelope: swells in lower-mid body, tapers to fine tip
const chord = chordBase * (1.0 + 0.65 * Math.sin(Math.PI * Math.pow(t, 0.7))) * (1.0 - 0.92 * Math.pow(t, 1.4));
const thick = thicknessBase * (1.0 - 0.82 * t);
const cosTw = Math.cos(currentTwist);
const sinTw = Math.sin(currentTwist);
for (let j = 0; j < M; j++) {
const alpha = (2 * Math.PI * j) / M;
const cx = -Math.cos(alpha) * chord * 0.5;
const cz = Math.sin(alpha) * thick * 0.5 * (1.0 - 0.45 * Math.cos(alpha));
// Rotate by local twist angle
const rx = cx * cosTw - cz * sinTw;
const rz = cx * sinTw + cz * cosTw;
positions.push(sx + rx, y, sz + rz);
uvs.push(j / M, t);
}
}
// Tip apex vertex for clean watertight convergence with cresting hook
const tipIdx = positions.length / 3;
const tipSx = sweepX - 0.035 * Math.sin(Math.PI * u);
const tipSz = 0;
const tipY = 0.045 + height;
positions.push(tipSx, tipY, tipSz);
uvs.push(0.5, 1.0);
// Bottom cap
for (let j = 0; j < M; j++) {
const nextJ = (j + 1) % M;
indices.push(bottomCenterIdx, 1 + nextJ, 1 + j);
}
// Side quads
for (let k = 0; k < K - 2; k++) {
const rowA = 1 + k * M;
const rowB = 1 + (k + 1) * M;
for (let j = 0; j < M; j++) {
const nextJ = (j + 1) % M;
const a0 = rowA + j;
const a1 = rowA + nextJ;
const b0 = rowB + j;
const b1 = rowB + nextJ;
indices.push(a0, a1, b1);
indices.push(a0, b1, b0);
}
}
// Top cap
const lastRow = 1 + (K - 2) * M;
for (let j = 0; j < M; j++) {
const nextJ = (j + 1) % M;
indices.push(lastRow + j, lastRow + nextJ, tipIdx);
}
return meshGeo({ positions, indices, uvs });
}
function build() {
const root = createRoot('MuseumKineticWaveSculpture');
// Museum Materials
const stoneMat = gameMaterial(0x1a1c20, { roughness: 0.82, metalness: 0.08, flatShading: false });
const stoneStepMat = gameMaterial(0x22252a, { roughness: 0.78, metalness: 0.10, flatShading: false });
const subBaseMat = gameMaterial(0x0f1012, { roughness: 0.90, metalness: 0.05, flatShading: false });
const bronzeMat = gameMaterial(0xba8548, { roughness: 0.26, metalness: 0.88, flatShading: false });
const polishedBronzeMat = gameMaterial(0xd49b42, { roughness: 0.20, metalness: 0.92, flatShading: false });
const tealMat = gameMaterial(0x187a82, { roughness: 0.32, metalness: 0.45, flatShading: false });
const darkMetalMat = gameMaterial(0x262a30, { roughness: 0.55, metalness: 0.75, flatShading: false });
// 1. Museum Plinth Base
// Recessed reveal foot (shadow gap at floor contact Y=0)
createPart('SubBaseFoot', boxGeo(0.52, 0.03, 1.72), subBaseMat, {
position: [0, 0.015, 0],
parent: root,
});
// Main dark stone plinth body
createPart('PlinthBody', boxGeo(0.60, 0.32, 1.80), stoneMat, {
position: [0, 0.19, 0],
parent: root,
});
// Inset top gallery tier step
createPart('PlinthTopTier', boxGeo(0.48, 0.04, 1.68), stoneStepMat, {
position: [0, 0.37, 0],
parent: root,
});
// Inset bronze reveal borders around top deck
createPart('InlayTrimFront', boxGeo(0.015, 0.01, 1.66), bronzeMat, {
position: [0.22, 0.392, 0],
parent: root,
});
createPart('InlayTrimBack', boxGeo(0.015, 0.01, 1.66), bronzeMat, {
position: [-0.22, 0.392, 0],
parent: root,
});
createPart('InlayTrimLeft', boxGeo(0.425, 0.01, 0.015), bronzeMat, {
position: [0, 0.392, -0.82],
parent: root,
});
createPart('InlayTrimRight', boxGeo(0.425, 0.01, 0.015), bronzeMat, {
position: [0, 0.392, 0.82],
parent: root,
});
// Museum catalog plaque on front face (+X face) with bronze frame and dark etched inlay
createPart('MuseumPlaqueFrame', boxGeo(0.008, 0.075, 0.17), polishedBronzeMat, {
position: [0.304, 0.20, 0],
parent: root,
});
createPart('MuseumPlaqueInlay', boxGeo(0.006, 0.063, 0.158), darkMetalMat, {
position: [0.306, 0.20, 0],
parent: root,
});
createPart('PlaqueScrewLeft', cylinderXGeo(0.002, 0.002, 0.008, 8), polishedBronzeMat, {
position: [0.3065, 0.20, -0.065],
parent: root,
});
createPart('PlaqueScrewRight', cylinderXGeo(0.002, 0.002, 0.008, 8), polishedBronzeMat, {
position: [0.3065, 0.20, 0.065],
parent: root,
});
// Base plinth bronze trim reveal
createPart('BasePlinthTrimFront', boxGeo(0.012, 0.006, 1.76), bronzeMat, {
position: [0.285, 0.036, 0],
parent: root,
});
createPart('BasePlinthTrimBack', boxGeo(0.012, 0.006, 1.76), bronzeMat, {
position: [-0.285, 0.036, 0],
parent: root,
});
createPart('BasePlinthTrimLeft', boxGeo(0.558, 0.006, 0.012), bronzeMat, {
position: [0, 0.036, -0.875],
parent: root,
});
createPart('BasePlinthTrimRight', boxGeo(0.558, 0.006, 0.012), bronzeMat, {
position: [0, 0.036, 0.875],
parent: root,
});
// 2. Mechanical Bed & Track
createPart('MechanismBed', boxGeo(0.14, 0.025, 1.54), darkMetalMat, {
position: [0, 0.4025, 0],
parent: root,
});
// Twin polished bronze guide rods running the full length
createPart('GuideRodFront', cylinderZGeo(0.007, 0.007, 1.52, 12), polishedBronzeMat, {
position: [0.045, 0.42, 0],
parent: root,
});
createPart('GuideRodBack', cylinderZGeo(0.007, 0.007, 1.52, 12), polishedBronzeMat, {
position: [-0.045, 0.42, 0],
parent: root,
});
// 3. Articulated Stations & Kinetic Wave Fins
const NUM_FINS = 17;
const START_Z = -0.68;
const STEP_Z = 0.085;
for (let i = 0; i < NUM_FINS; i++) {
const zi = START_Z + i * STEP_Z;
const u = i / (NUM_FINS - 1); // 0 to 1 along wave
// Stationary bearing pillow blocks on track
createPart(`PillowBlockFront_${i}`, boxGeo(0.026, 0.065, 0.035), bronzeMat, {
position: [0.048, 0.4475, zi],
parent: root,
});
createPart(`PillowBlockBack_${i}`, boxGeo(0.026, 0.065, 0.035), bronzeMat, {
position: [-0.048, 0.4475, zi],
parent: root,
});
createPart(`BearingCapFront_${i}`, cylinderXGeo(0.014, 0.014, 0.015, 12), polishedBronzeMat, {
position: [0.055, 0.48, zi],
parent: root,
});
createPart(`BearingCapBack_${i}`, cylinderXGeo(0.014, 0.014, 0.015, 12), polishedBronzeMat, {
position: [-0.055, 0.48, zi],
parent: root,
});
// Rooted Articulated Pivot Node
const pivot = createPivot(`Fin_${i}`, [0, 0.48, zi], root);
// Transverse axle through the bearings
createPart(`Axle_${i}`, cylinderXGeo(0.008, 0.008, 0.125, 16), polishedBronzeMat, {
parent: pivot,
});
createPart(`CentralHub_${i}`, cylinderXGeo(0.016, 0.016, 0.045, 16), bronzeMat, {
parent: pivot,
});
// Articulated root clasp gripping the fin blade
createPart(`RootClasp_${i}`, boxGeo(0.038, 0.042, 0.034), bronzeMat, {
position: [0, 0.024, 0],
parent: pivot,
});
// Downward counterweight pendulum
createPart(`CounterweightArm_${i}`, cylinderYGeo(0.0055, 0.0055, 0.12, 12), darkMetalMat, {
position: [0, -0.06, 0],
parent: pivot,
});
createPart(`CounterweightBob_${i}`, cylinderYGeo(0.018, 0.022, 0.045, 16), polishedBronzeMat, {
position: [0, -0.13, 0],
parent: pivot,
});
// Stationary mounting plate anchoring bearing to stone plinth
createPart(`AnchorPlate_${i}`, boxGeo(0.12, 0.008, 0.05), bronzeMat, {
position: [0, 0.418, zi],
parent: root,
});
// Coherent Progressive Silhouette Parameters: undulating wave crescendo
const height = 0.46 + 0.30 * Math.sin(Math.PI * u) + 0.32 * Math.pow(Math.sin(Math.PI * Math.pow(u, 0.85)), 2.5);
const sweepX = 0.10 + 0.24 * Math.pow(u, 1.15) + 0.04 * Math.sin(Math.PI * u);
const archZ = 0.12 * Math.sin(2.0 * Math.PI * u);
const twistDeg = -12.0 * Math.cos(Math.PI * u) + 14.0 * (u - 0.5);
const chordBase = 0.068 + 0.022 * Math.sin(Math.PI * u);
const thicknessBase = 0.017;
// Fin blade material: alternate rich teal and warm bronze
const isTeal = (i % 2 === 0);
const finMat = isTeal ? tealMat : bronzeMat;
const bladeGeo = createFinBladeGeo(u, height, sweepX, archZ, twistDeg, chordBase, thicknessBase);
createPart(`Blade_${i}`, bladeGeo, finMat, {
parent: pivot,
});
// Articulated bronze clamping cuffs and aerodynamic heel spur
const upperT = 0.09;
const upperY = 0.045 + height * upperT;
const upperSx = sweepX * Math.pow(upperT, 1.75);
const upperSz = archZ * Math.sin(Math.PI * upperT);
createPart(`ClampBandLower_${i}`, boxGeo(0.042, 0.014, 0.038), polishedBronzeMat, {
position: [0, 0.045, 0],
parent: pivot,
});
createPart(`ClampBandUpper_${i}`, boxGeo(0.036, 0.012, 0.032), polishedBronzeMat, {
position: [upperSx, upperY, upperSz],
parent: pivot,
});
createPart(`ClampingBolt_${i}`, cylinderXGeo(0.003, 0.003, 0.044, 8), polishedBronzeMat, {
position: [0, 0.045, 0],
parent: pivot,
});
createPart(`HeelSpur_${i}`, cylinderYGeo(0.009, 0.004, 0.075, 12), polishedBronzeMat, {
position: [-0.014, 0.055, 0],
rotation: [0, 0, 16],
parent: pivot,
});
}
return root;
}
// Coordinated flowing wave animation
function animate(root) {
const NUM_FINS = 17;
const duration = 4.0;
const tracks = [];
const keyframeTimes = [0, 0.5, 1.0, 1.5, 2.0, 2.5, 3.0, 3.5, 4.0];
for (let i = 0; i < NUM_FINS; i++) {
// 2 complete wave crests propagating along the 17 stations
const phase = (2 * Math.PI * i) / 8.0;
const keyframes = [];
for (const t of keyframeTimes) {
const angle = (2 * Math.PI * t) / duration - phase;
// Primary tilt forward/backward (Z rotation)
const rotZ = 15.0 * Math.sin(angle);
// Secondary lateral sway (X rotation)
const rotX = 5.5 * Math.cos(angle);
// Subtle compound yaw precession
const rotY = 2.0 * Math.sin(2.0 * angle);
keyframes.push({
time: t,
rotation: [rotX, rotY, rotZ],
});
}
tracks.push(rotationTrack(`Joint_Fin_${i}`, keyframes));
}
return [createClip('FlowingWave', duration, tracks)];
}Scroll code horizontally
Brief and retained revisions
Brief summary
Create a kinetic museum sculpture with bronze and teal curved fins, a deliberate flowing silhouette, a dark stone base and coordinated wave animation.
Initial design
First retained sculpture with curved fins and coordinated pivot animation.
Download initial design sourceSHA-256: a49616fba7ea7df347e0cc2ec34561d80ed4d12ad800d870d2fd22ace0b6a96f
Mounting and silhouette revision
Added mounting plates and a framed plaque, then reshaped the height progression into a clearer wave.
Download mounting and silhouette revision sourceSHA-256: 8cc3251317a820b42fd61c3a1f827fea48a0fd2d25b1c5dd60fcceb967fb42a3
Previous gallery revision
Curled the fin tips, moved upper clamps to follow the curved fins, and added plaque fasteners.
Download previous gallery revision sourceSHA-256: 5a4ef2784d7a49e58c9dba495a97bae1bad948d4d9569e65607d97ebddb40151
Flush faces fixed · Shown here
Maintainer revision by Claude Sonnet 5.5 via Claude Code (2026-11-12): 1 part edit that separates faces lying on one plane, which flickered in any renderer. Materials, names, hierarchy and animation are unchanged.
Download flush faces fixed sourceSHA-256: fd9973630d17faf48d8486f2a62edf951f9873357436cf14e8c3a8c99424f66f
